Metacaulk® Putty

Metacaulk® Putty is a soft, pliable, and reusable firestopping compound that offers a convenient and effective solution for sealing penetrations in fire-rated assemblies. Its key features and details include

Key Features

• Highly Intumescent: Expands significantly when exposed to heat from a fire, forming a robust char that seals the penetration and prevents the passage of flames and smoke. Expansion begins at approximately 250°F (121°C).
• Non-Sag: Easy to mold and apply by hand to both horizontal and vertical surfaces without dripping or slumping.
• Re-enterable: Allows for easy removal and re-application when changes or additions to penetrants are required, making it ideal for areas with frequent MACs.
• Easy to Install: Requires no mixing or special tools. Simply mold the putty around the penetrating item and press it into the annular space.
• Cost-Effective: The re-enterable nature can reduce the need for new firestop materials during cable or pipe changes.
• Tested for Various Penetrants: Classified by Underwriters Laboratories (UL) for use with a wide range of penetrants, including:
  • Electrical cables and cable bundles (single and multiple)
  • Communication cables (fiber optic, data, etc.)
  • Insulated and non-insulated metal pipes
  • Non-metallic pipes (in certain UL listed systems)
• Fire Ratings up to 4 Hours: Provides fire ratings up to 4 hours in accordance with UL 1479 (ASTM E814) and CAN/ULC-S115, depending on the specific penetration and construction assembly.
• Smoke and Gas Tight Seal: Helps to prevent the passage of smoke and toxic gases.
• Excellent Adhesion: Adheres well to common construction materials and cable/pipe jacketing.
• Halogen-Free: Does not contain halogenated compounds.
• FBC System Compatible: Indicates that the product has been tested and is monitored on an ongoing basis to assure its chemical compatibility with FlowGuard Gold®, BlazeMaster®, and Corzan® pipe 1 and fittings.

Applications

• Firestopping electrical cables and cable bundles penetrating fire-rated walls and floors.
• Firestopping communication cables (fiber optic, data, etc.) penetrating fire-rated walls and floors.
• Firestopping insulated and non-insulated metal pipes penetrating fire-rated walls and floors.
• Firestopping non-metallic pipes (in specific UL listed systems) penetrating fire-rated walls and floors.
• Sealing small openings and gaps in fire-rated assemblies.
• Ideal for use in areas where frequent cable or pipe changes are anticipated, such as:
  • Data centers
  • Telecommunication rooms
  • Electrical rooms
  • Healthcare facilities
  • Commercial buildings

Installation

1. Select the appropriate amount of putty based on the size and number of penetrants and the size of the opening.
2. Clean the surfaces of the penetrating items and the surrounding fire-rated assembly.
3. Mold the putty to fit snugly around the penetrants, filling the entire annular space within the penetration.
4. Press the putty firmly into place, ensuring good contact with the penetrants and the surrounding construction.
5. Ensure the putty is flush with the surface of the wall or floor assembly.
6. For larger openings or specific applications, additional putty or other firestop materials may be required as specified in the UL listing.
7. Consult the specific UL Directory listing for the exact installation details for the penetrating items and fire-rated assembly.

For detailed technical specifications, UL system listings, application instructions, and safety data sheets for specific Metacaulk® Putty products, always refer to the official product documentation from us.
